VL SERIES MANUAL

DESIGN:

Full Lug

MATERIALS:

Solid Cast 316 Stainless Steel Body 316 Hard Chrome Coated Gate

SIZE:

Carbon Steel, Cast Ni-Resist, Ductile Iron, Ductile Ni-Resist, Special Cast Material, Stainless Steel

FLANGE DRILLING:

ANSI 150

FACE-TO-FACE:

TAPPI & MSS-SP81

PRESSURE RATING:

Size 2”-12” 150 psi Shut-off
Size 14”-24” 90 psi Shut-off
Higher Pressure Ratings available

Solid Steel Heavy Duty 4-Post Topworks

Suitable for Dead-end Service
